SB 100 (SPRAY GRADE)

SB-100 is an environmentally friendly, elastomeric bitumen emulsion and the basis for a high performance, cost efficient liquid applied roof waterproofing membrane. Spray applied in combination with an inorganic rapid set accelerator, SB-100 instantly forms a rubberized, fully adhered waterproof membrane for new and restoration roofing projects.

SB-100 is applied using the HVLP 2000, a dual diaphragm pump system that is easy to use and has been specifically designed by SBH SEAL LLC. SB-100 is sprayed concurrently with an inorganic salt solution that transforms the product as a liquid into a seamless rubberized membrane as it contacts with the roof deck surface.

SB-100 spray on liquid membrane fully cures in less than 24 hours but is waterproof instantly! Thus protecting your building from the rain and water infiltration.

Cold applied directly to surface with minimal prep, at any thicknessFully adhered to avoid water tracking or water buildup under surfaceMonolithic and seamless, can be installed around obstacles with easeCan be applied to complex irregular penetrations without joints100% VOC free, solvent free, non-hazmat, water-basedHighly elastomeric ( > 1,332% ) for concrete crack bridging
Highly weather resistant to UV, freeze and thaw, solar oxidationUses include: roofing, foundations, under-slab, blindside and laggingExcellent chemical resistance properties for containment protectionApplied at 4 to 6 times the coating thickness of competing technologiesOver 138' (42m) resistance to hydrostatic head water pressure

SB 100 (SPRAY GRADE)

SB-100 is an environmentally friendly, elastomeric bitumen emulsion and the basis for a high performance, cost efficient liquid applied roof waterproofing membrane. Spray applied in combination with an inorganic rapid set accelerator, SB-100 instantly forms a rubberized, fully adhered waterproof membrane for new and restoration roofing projects.

SB-100 is applied using the HVLP 2000, a dual diaphragm pump system that is easy to use and has been specifically designed by SBH SEAL LLC. SB-100 is sprayed concurrently with an inorganic salt solution that transforms the product as a liquid into a seamless rubberized membrane as it contacts with the roof deck surface.

At 25°C and 50% relative humidity, SB-100 fully cures in 24-48 hours. Curing time increases in colder temperatures or higher humidity so environmental conditions must be considered before application.

Cold applied directly to surface with minimal prep, at any thickness
Fully adhered to avoid water tracking or water buildup under surface
Monolithic and seamless, can be installed around obstacles with ease
Can be applied to complex irregular penetrations without joints
100% VOC free, solvent free, non-hazmat, water-based
Highly elastomeric ( > 1,332% ) for concrete crack bridging
Highly weather resistant to UV, freeze and thaw, solar oxidation
Uses include: roofing, foundations, under-slab, blindside and lagging
Excellent chemical resistance properties for containment protection
Applied at 4 to 6 times the coating thickness of competing technologies
Over 138' (42m) resistance to hydrostatic head water pressure

Relevant Documents:

SB 200 (BRUSH GRADE)

SB-200 is a single-component, liquid applied waterproofing sealant combining high quality bitumen with various polymers that forms a high-performance elastomeric waterproof membrane. Containing no solvents, SB-200 Waterproof Sealant is non-flammable and the coating will not damage polyurethane or polystyrene insulation materials. A variety of different reinforcing fabrics can be imbedded into the membrane to produce a high strength, superior waterproofing layer.

SB-200 is applied using a brush, roller or single component sprayer to provide a seamless and fully adhered membrane to most substrates. This all-purpose waterproofing sealant is designed for multiple surfaces including roofing materials and concrete as well sealing cracks, joins and flashings.

At 25°C and 50% relative humidity, SB-200 fully cures in 24-48 hours. Curing time increases in colder temperatures or higher humidity so environmental conditions must be considered before application.

Cold applied directly to surface with minimal prep, at any thicknessFully adhered to avoid water tracking or water buildup under surfaceMonolithic and seamless, can be installed around obstacles with easeCan be applied to complex irregular penetrations without joints100% VOC free, solvent free, non-hazmat, water-basedHighly elastomeric ( > 1,332% ) for concrete crack bridging
Highly weather resistant to UV, freeze and thaw, solar oxidationUses include: roofing, foundations, under-slab, blindside and laggingExcellent chemical resistance properties for containment protectionApplied at 4 to 6 times the coating thickness of competing technologiesOver 138' (42m) resistance to hydrostatic head water pressure

SB 200 (BRUSH GRADE)

SB-200 is a single-component, liquid applied waterproofing sealant combining high quality bitumen with various polymers that forms a high-performance elastomeric waterproof membrane. Containing no solvents, SB-200 Waterproof Sealant is non-flammable and the coating will not damage polyurethane or polystyrene insulation materials. A variety of different reinforcing fabrics can be imbedded into the membrane to produce a high strength, superior waterproofing layer.

SB-200 is applied using a brush, roller or single component sprayer to provide a seamless and fully adhered membrane to most substrates. This all-purpose waterproofing sealant is designed for multiple surfaces including roofing materials and concrete as well sealing cracks, joins and flashings.

At 25°C and 50% relative humidity, SB-200 fully cures in 24-48 hours. Curing time increases in colder temperatures or higher humidity so environmental conditions must be considered before application.

SPRAY ON MEMBRANE TRAINING VIDEOS

SPRAY ON MEMBRANE TRAINING VIDEOS

SPRAY ON / BRUSH ON GALLERY

INSTALLATION INSTRUCTIONS

Technical Data Sheet (TDS)

Safety Data Sheet (MSDS)

SB-200 Brush Grade

SB-248 Mesh Guide
